10 QTY Corcom SC2MM | 2A 250V Dual Fuse Holder | Low-Profile

$18.00
Unit price per

Shipping calculated at checkout.

Product Specifications:

Corcom SC2MM Fuse Holder

• Manufacturer: TE Connectivity / Corcom

• Series: SC Series (Circuit Protection)

• Component Type: Dual-Line Through-Hole (THT) Fuse Holder

• Current Rating: 2.0 Amps (Maximum per line)

• Voltage Rating: 250V AC / 100V DC

• Number of Poles: 2 (Dual independent fuse positions)

• Mounting Type: Through-Hole (PC Pin)

• Termination Style: Solder Pins / Leads

• Housing Material: High-Temperature Thermoplastic (UL 94V-0 Rated)

• Operating Temperature Range: -40°C to +85°C

• Compliance: RoHS Compliant

Key Features & Applications

• Dual-Line Protection: Houses two independent fuses in a single through-hole package, ideal for protecting both the "Line" and "Neutral" paths in 220V–250V AC circuits.

• Robust Through-Hole Mounting: Provides superior mechanical strength compared to surface mount alternatives, making it ideal for power-entry stages that may experience physical stress or vibration.

• High-Voltage Safety: Designed to meet industrial creepage and clearance standards for 250V AC operation, ensuring safe isolation between circuits.

• Compact footprint: Specifically engineered for dense PCB layouts where vertical height is limited but through-hole reliability is required.

• Common Applications:

• 220V AC Power Input Fusing

• Industrial Power Supplies and Motor Controllers

• Legacy Audio/Video Equipment Power Stages

• Telecommunications Line Protection
