Description
Product Specifications:
Corcom 20ESFLTN1 Power Module
• Manufacturer: TE Connectivity / Corcom
• Series: ESF Series (Power Entry / Fuse Protection)
• Component Type: Integrated Power Entry Module with Single Fuse Holder
• Current Rating: 20.0 Amps (UL/CSA) / 16.0 Amps (VDE)
• Voltage Rating: 250V AC
• Mounting Style: Threaded Barrel with Hex Nut (Panel Mount)
• Termination Style: .250" (6.3mm) Quick Connect / Solder Tabs
• Fuse Compatibility: Designed for standard 5x20mm or 1/4" x 1-1/4" fuses (verify internal clip)
• Housing Material: High-Strength Thermoplastic (UL 94V-0 Rated)
• Operating Temperature Range: -10°C to +40°C
• Safety Approvals: UL Recognized, CSA Certified, VDE Approved
Key Features & Applications
• Secure Threaded Mounting: Unlike snap-in versions, the threaded barrel and heavy-duty hex nut provide a high-torque, vibration-resistant connection to the chassis or panel.
• High-Current Capacity: Rated up to 20A, making it suitable for high-performance power supplies, industrial equipment, and large-scale audio amplifiers.
• Front-Access Fuse Drawer: Allows for rapid fuse inspection and replacement from the exterior of the equipment without opening the main enclosure.
• Integrated Safety: Combines the AC power inlet and primary circuit protection into one shielded unit, reducing internal wiring and improving EMI performance.
